Silikon simning tavsifi:
500V 1000V moslashuvchan qalay mis o'tkazgich silikon kauchuk izolyatsiya qilingan silikon sim
Turi nomi: JG moslashuvchan silikon sim
Nominal kuchlanish: 500V, 1000V
Harorat ko'rsatkichlari: -60ºC ~ -180ºC
Ilova:.
Silikon sim turli xil elektr mashinalari, motorlar, maishiy texnika, elektr keramika, isitish elementlari qismlari, elektrni tekshirish uskunalari, avtoulov chiroqlari, avto lampalar, yoritish lampasi, barretter va boshqalar uchun keng qo'llaniladi.
Moslashuvchan silikon sim uchun kabel tuzilishi:
Supero'tkazuvchilar: yalang'och mis yoki qalaylangan mis simli sim
Izolyatsiya: silikon kauchuk
Silikon sim uchun ruxsat etilgan OD bardoshlik darajasi: ± 0,1 mm
Rang: qora, jigarrang, qizil, yashil, binafsha, oq, kulrang, shaffof va boshqa ranglarni mijozning talablariga binoan sozlash mumkin.
500V 1000V moslashuvchan silikon sim uchun spetsifikatsiya
Oddiy o'lcham: 0,5 mm, 0,75 mm, 1,0 mm, 1,5 mm ......... dan 240 mm gacha
Issiq savdo xususiyatlari: 0.75mm, 1.0mm, 1.5mm, 2.0mm, 2.5mm, 4.0mm
Pastak kuchlanishli moslashuvchan silikon sim uchun UL spetsifikatsiyasi:
Nominal kuchlanish: 300V 600V
Harorat ko'rsatkichlari: -60ºC ~ -200ºC
UL silikon simini issiq sotish: UL3135, UL3142, UL3529, UL 3530
Issiq savdo ul xususiyatlari: 10awg, 12gauge, 14 awg, 14 gauge, 16 gauge, 18 gauge 20awg
Past kuchlanishli moslashuvchan silikon sim uchun texnik ma'lumotlar ro'yxati
|
| Tashqi diametri |
| ||||
|
| Diametri | 500V | 1000V | 500V | 1000V | Maks. Supero'tkazuvchilar |
0.5 | 28/0.15 | 0.9 | 1 | 1.2 | 2.9 | 3.3 | 40.1 |
0.75 | 24/0.2 | 1.15 | 1 | 1.2 | 3.2 | 3.6 | 26.7 |
1 | 32/0.2 | 1.3 | 1 | 1.2 | 3.3 | 3.7 | 20 |
1.5 | 48/0.2 | 1.6 | 1 | 1.2 | 3.6 | 4 | 13.7 |
2 | 40/0.25 | 1.85 | 1 | 1.2 | 3.9 | 4.3 | 9.9 |
2.5 | 49/0.25 | 2 | 1 | 1.2 | 4 | 4.4 | 8.21 |
4 | 56/0.3 | 2.8 | 1.2 | 1.4 | 5.2 | 5.6 | 5.09 |
6 | 84/0.3 | 3.6 | 1.2 | 1.5 | 6 | 6.6 | 3.39 |
10 | 84/0.4 | 4.6 | 1.4 | 1.6 | 7.4 | 7.8 | 1.95 |
16 | 126/0.4 | 5.8 | 1.4 | 1.6 | 8.6 | 9 | 1.24 |
25 | 196/0.4 | 7.6 | 1.6 | 1.8 | 10.8 | 11.2 | 0.795 |
35 | 494/0.3 | 8.8 | 1.8 | 2 | 12.4 | 12.8 | 0.565 |
50 | 396/0.4 | 10.6 | 2 | 2.2 | 14.6 | 15 | 0.393 |
70 | 551/0.4 | 12.8 | 2 | 2.2 | 16.8 | 17.2 | 0.277 |
95 | 760/0.4 | 14.8 | 2.2 | 2.5 | 19.2 | 19.8 | 0.21 |
120 | 608/0.5 | 16.5 | 2.2 | 2.5 | 21 | 21.5 | 0.164 |
150 | 760/0.5 | 18.2 | 2.4 | 2.6 | 23 | 23.4 | 0.132 |
185 | 925/0.5 | 20 | 2.4 | 2.6 | 24.8 | 25.2 | 0.108 |
240 | 1221/0.5 | 23 | 2.6 | 2.8 | 28.2 | 28.6 | 0.0817 |
